Finished product will be of round pipe, square and rectangle pipe.
Feeding strip→ Uncoiler→Peeler→Fiveroll Flattening→shear and end welder→ Spiral accumulator→ Forming→High-frequency induction welding→Removing Externalburr→ Polishing Roller→WaterCooling→ Sizing→CuttingSaw→ Pullout roller table→ Weighing and Measuring→ Painting andMarking→Packing→ Warehousing
| Pipe Parameter | |
| Round pipe | Φ114mm-Φ219mm |
| Square&Rectanglepipe | 80X80mm-150X150mm |
| Pipe length | 6m |
| Packing Type | |
| Fully automatic | No seal punching type bundling machine head |
| Packing belt quantity | 4 |
| Width | 32mm |
| Thickness | 1.0mm |
| OD | 800mm |
| Width | 200mm |
| Max tension | 20000N |
| The junction plane width is not less than the belt width. The length is not less than 150mm.( The circular arc diameter is not less thanΦ750mm) | |
